Mobile POS HM628N

For life on the go

9614a2_012ac275ec5946e4ba7a07d0b2fd7199_mv2
9614a2_f91323b94cde497f889074411a60ee4f_mv2
9614a2_2ffb1c923f9c4986862ddae175e3998a_mv2
9614a2_59aa088d05fa4972ae365687462674d8_mv2

THE POWER TO SERVE

Mobile and ruggedized, the HM628N / HM626R POS tablet from HiStone is the ultimate device for businesses requiring a versatile and robust system that offers maximum flexibility. The PCAP multi-touch 10.1" display with a wide viewing angle and bezel-free design provides clear visibility from various angles delivering an exceptional customer and user experience.

SPECIFICATIONS

HM628N - Windows
HM626R - Android

CPU

  • Intel® Celeron N4120 Quad-core 1.1GHz up to 2.6GHz
  • ARM RK3288 (4core) 1.6GHz
  • ARM RK3288 (4core) 1.8 GHz

OPERATING SYSTEM

  • Windows 10
  • Android 7.1

MEMORY

  • 4GB
  • 2GB
  • 4GB

STORAGE

  • 64GB eMMC
  • 16GB eMMC
  • 64GB eMMC

MAIN DISPLAY

  • 10.1" TFT LCD (LED backlight), 1280 x 800 True Flat Capacitive Touch
  • 10.1" TFT LCD (LED backlight), 1280 x 800 True Flat Capacitive Touch

PRINTER

  • Integrated 58mm thermal printer (Available with Optional Smart Docking Station)
  • Integrated 58mm thermal printer (Available with Optional Smart Docking Station)

BARCODE SCANNER

  • Integrated 1D or 2D (Optional)
  • Integrated 1D or 2D (Optional)

MSR

  • 3 Tracks (Default)
  • Magtek Encrypted (Optional)
  • 3 Tracks (Default)
  • Magtek Encrypted (Optional)

RFID

  • 3 Tracks MSR & RFID - OPOS (Optional)
  • 3 Tracks MSR & RFID - OPOS (Optional)

WI-FI

  • Dual-band 2.4GHz/5GHz
  • Dual-band 2.4GHz/5GHz

BLUETOOTH

  • BT 4.1
  • BT 4.1

POWER SUPPLY

  • 12V 2A (Tablet & Charging Dock)
  • 24V 90W (Smart Dock)
  • 12V 2A (Tablet & Charging Dock)
  • 24V 90W (Smart Dock)

DIMENSIONS (WxDxH)

  • 282 x 198 x 18 mm (Tablet)
  • 151 x 92 x 121mm (Charging Dock)
  • 236 x 218 x 150-370 mm (Smart Dock)
  • 282 x 198 x 18 mm (Tablet)
  • 151 x 92 x 121mm (Charging Dock)
  • 236 x 218 x 150-370 mm (Smart Dock)

WEIGHT

  • 1kg (Tablet)
  • 325g (Charging Dock)
  • 2.82kg (Smart Dock)
  • 1kg (Tablet)
  • 325g (Charging Dock)
  • 2.82kg (Smart Dock)

SPEAKER

  • 2 x 1W
  • 2 x 1W

ENVIRONMENT

  • Operating 5°C - 40°C
  • Storage -20°C - 60°C
  • Operating 5°C - 40°C
  • Storage -20°C - 60°C


I/O PORTS - TABLET

  • 2* USB Port (1* Micro)
  • 1* 3.5mm Audio
  • 1* HDMI Micro
  • 1* 12V 2A Power Out
  • 1* SIM Card (Nano)
  • 1* TF Card up to 32GB
  • 2* USB Port (1* Micro)
  • 1* 3.5mm Audio
  • 1* HDMI Micro
  • 1* 12V 2A Power Out
  • 1* SIM Card (Nano)
  • 1* TF Card up to 32GB

I/O PORTS - CHARGING DOCK

  • 2* USB
  • 2* USB

I/O PORTS - SMART DOCK

  • 3* USB
  • 2* RS232 Serial
  • 1* 100M LAN Ethernet
  • 1* RJ11 (D-24V) Cash Drawer
  • 3* USB
  • 2* RS232 Serial
  • 1* 100M LAN Ethernet
  • 1* RJ11 (D-24V) Cash Drawer
